The CALL statement causes control to be transferred to a specific program within the run unit.
You can call the program indirectly,
by address. Data, pointers to data, and pointers to procedures can be passed as
parameters to the called program, and returned by it. Parameter passing
conventions can be controlled in order to allow the called program to be
written in languages other than COBOL, using different conventions.
A called COBOL program can
recursively call itself when it has the recursive attribute.
Format 2
(program-prototype)
Syntax rules marked with an asterisk (*) are common to the CALL statement and to the CHAIN statement. In these rules, where "CALL or CHAIN statement" is specified, you should read "CALL statement" or "CHAIN statement" when applying the rules to the CALL statement or the CHAIN statement respectively.
or
national
data item.
, literal-2
, and literal-3
cannot be a figurative constant and must be an alphanumeric literal
or a
national literal.
Local-Storage
Section
or Linkage Section, and must be a level 01 data item, or a level 77 data item
, or an elementary
item
, or any
group item.
Identifier-2 must not be defined in the
Working-Storage or File Section of a factory or an instance object.
* Neither identifier-5, identifier-6,
identifier-7, nor identifier-8 can be a function-identifier. * GIVING and RETURNING are equivalent.
Identifier-9 must be defined as a data
item in the Linkage Section with a level number of 01 or 77. *Identifier-2, identifier-4, identifier-6
and identifier-8 must not be described with the ANY LENGTH clause. Mnemonic-name is necessary only if the
object program that is to be invoked expects a calling convention other than
that used as the default by your COBOL system. Typically, the default COBOL
calling convention is consistent with that used by a significant implementation
of a non-COBOL language for the run-time environment.
Mnemonic-name must be defined in the Special-Names paragraph. See the topic The Special-Names Paragraph for details of how to do this and your COBOL system documentation on interfacing for details of which calling conventions are supported in your run-time environment.
* Integer-1 may be signed. * Identifier-3 must be defined as a
data item in the Linkage Section
, Local-Storage
Section or Working-Storage Section,
and must be a level 01 data item, a level 77 data item
, or other level data
item.
If the CALL statement specifies literal-1 (but not if it
specifies identifier-1 or procedure-pointer-1), and if a call prototype (a
program with the EXTERNAL clause in its Program-ID paragraph) has been included
in the current compilation unit with a name that matches literal-1, then the
following items are validated during syntax checking:
* Identifier-2 must not be a data
item of class object or pointer. Format
2The NESTED phrase must be specified only in a
program definition. If the NESTED phrase is specified, literal-1 must
be specified. Literal-1 must be the same as the program-name specified in the
Program-ID paragraph of a common program as specified in the topic
Conventions for
Program-names in the chapter Concepts of the
COBOL Language or of a program that is directly contained in the calling
program. Program-prototype-name-1 must be specified in a
program-specifier in the Repository paragraph. If the BY CONTENT or BY REFERENCE phrase is
specified or implied for an argument, the BY REFERENCE phrase must be specified
for the corresponding formal parameter in the PROCEDURE DIVISION header. BY CONTENT must not be omitted when identifier-4
is an identifier that is permitted as a receiving operand, except that BY
CONTENT may be omitted when identifier-4 is an object property. If the BY VALUE phrase is specified for an
argument, the BY VALUE phrase must be specified for the corresponding formal
parameter in the PROCEDURE DIVISION header. Identifier-6 must be of class numeric, object, or
pointer. Literal-4 must be a numeric literal. If the OMITTED phrase is specified, the OPTIONAL
phrase must be specified for the corresponding formal parameter in the
PROCEDURE DIVISION header. The rules for conformance specified in the topic
Conformance for Parameters and
Returning Items in the chapter Procedure
Division apply. General rules marked with an asterisk (*) are common to the CALL statement and to the CHAIN statement. In these rules, where "CALL or CHAIN statement" are specified, you should read "CALL statement" or "CHAIN statement" when applying the rules to the CALL statement or the CHAIN statement respectively.
or called procedure.
The program in which the CALL statement appears is the calling program. If the program being called is a COBOL program, literal-1 or the content of the data item referenced by identifier-1 must contain the program-name contained in the Program-ID paragraph of the called program (see the topic The Program-ID Paragraph, particularly in regard to case sensitivity),
or the entry-name
contained in the ENTRY statement of a called program that must have been called
previously and not canceled since. Alternatively, the name of the called
program may be a name which identifies a file that contains executable program
code for the called program. The result of specifying different names that
identify the same file in two CALL statements or a CALL and a CANCEL statement
are operating-system specific. See your COBOL system documentation for details
of how your system matches the given name to previously called programs,
program filenames or programs held in library files.
If the program being called is not a
COBOL program, the rules for the formation of the program or procedure name are
given in the COBOL system documentation on interfacing.
The content of the data item referenced by
procedure-pointer-1 is the address of the called program that must be already
resident in memory. If the program being called is a COBOL program, the address
of the called program must originally have been derived from a SET statement
with an ENTRY phrase and no CANCEL statement for that program must have been
subsequently executed. If the program being called is not a COBOL program then
the address of the called program must originally have been derived from a CALL
to a non-COBOL program or procedure. It is an error to attempt to CALL a
program with an address that is equal to NULL. or ON EXCEPTION
phrase is ignored and control is passed to the end of the CALL statement
or, if the NOT ON
EXCEPTION phrase is specified control is passed to imperative-statement-2. If
control is passed to imperative-statement-2, execution continues according to
the rules for each statement specified in imperative-statement-2. If a
procedure branching or conditional statement which causes explicit transfer of
control is executed, control is transferred in accordance with the rules for
that statement; otherwise, upon completion of the execution of
imperative-statement-2, control is transferred to the end of the CALL
statement.
If the program specified by the CALL is not resident in memory, is not available for dynamic loading or is available but is too large for the available memory, then the program cannot be made available at that time and one of the following two actions occurs:
or ON
EXCEPTION
phrase is specified in the CALL statement, control is transferred to imperative-statement-1. Execution then continues according to the rules for each statement specified in imperative-statement-1. If a procedure branching or conditional statement which causes explicit transfer of control is executed, control is transferred in accordance with the rules for that statement; otherwise, upon completion of execution of imperative-statement-1, control is transferred to the end of the CALL statement
and the NOT ON
EXCEPTION phrase, if specified, is ignored.
If the ON
OVERFLOW or ON EXCEPTION phrase is not specified in the CALL statement, the NOT
ON EXCEPTION phrase, if specified, is ignored. Program execution stops, without an
implicit CLOSE statement for any file that is in open mode in the run unit, and
a run time error is displayed.
Two or more COBOL programs in the run unit can have the same
program-name, and the reference in a CALL statement to such a program-name is
resolved by using the scope-of-names conventions for program-names. See the
topic
Conventions for Program-names
in the chapter Concepts of the COBOL
Language. For example, when two programs in the run unit have the same
name as that specified in a CALL statement:
The mechanism used in this example is as follows:
If the called program is not COBOL, it is only in its initial state the first time it is called within a run unit. A CANCEL of such a program has no effect.
On all other entries into the called program, the state of the program and each program directly or indirectly contained within it remains unchanged from its state when last exited. Some implementations of languages other than COBOL may provide alternative semantics and, if available, these are detailed in your COBOL system documentation on interfacing.
If the called program possesses the
intial attribute, it and each program directly or indirectly contained within
it, is placed into its initial state every time the called program is called in
a run unit. Whether a called program is in the initial state or last-used state
is sensitive to the DYNAM Compiler directive. Files associated with a called
program's internal file connectors are not in the open mode when the program is
in an initial state. See the topicIntial State Of A Program
earlier in this chapter. On all other entries into the called program, the
states and positioning of all such files are the same as when the called
program was last exited. The process of calling a program or
exiting from a called program does not alter the status or positioning of a
file associated with any external file connector.
or ENTRY
statement
of the called program, in which case the number of operands in each USING phrase must be identical.
The number of operands need not be
identical.
If the program being called is not a COBOL
program, the USING phrase is included in the CALL statement only if one or more
parameters are declared for the called program, in which case the number of
operands in the USING phrase must be identical to the number of parameters in
the called program. (Some implementations of languages other than COBOL may
allow the number of operands to be other than identical.) The COBOL language
places no restrictions on the alignment of the addresses of data items, whereas
non-COBOL languages typically do make assumptions about addresses and will fail
in some way if a misaligned data item is referenced. Alignment can be achieved
by one or more of the following actions:
or CHAIN
statement and in the corresponding USING phrase in the called program's PROCEDURE DIVISION header
or ENTRY statement or
parameter list if the called program is not COBOL
determines the correspondence between the data names used by the calling and called programs. This correspondence is positional and not by name equivalence; the first operand in the CALL
or CHAIN
statement's USING phrase corresponds to the first operand in the called program's USING phrase or parameter list, the second to the second, etc.
If the correspondence cannot be completed
because the numbers of operands are different, then if the remaining unmatched
operands are in the CALL or CHAIN statement they are ignored and if they are in
the PROCEDURE DIVISION header or ENTRY statement or parameter list then they
must not be referenced within the called program. The positional correspondence
may vary depending on the calling conventions implied by mnemonic-name.
In the case of index-name, no such correspondence is established. Index-names in the called and calling programs always refer to separate indices.
* The values of the parameters
referenced in the USING phrase of the CALL statement are made available to the
called program at the time the CALL statement is executed. either specified
or
implied for a parameter, the program operates as if the corresponding data item in the called program occupies the same storage area as the data item in the calling program. The description of the data item in the called program must describe the same number of character positions as described by the description of the corresponding data item in the calling program.
If the BY REFERENCE ADDRESS OF
phrase is specified or implied then the program operates as if an additional
data item had been declared with USAGE POINTER and that data item passed BY
REFERENCE with a value acquired by a SET data item TO ADDRESS OF identifier-3
statement.
If identifier-3 is in the Linkage
Section and has a level number other than 01 or 77 or is in the Working-Storage
Section, this is equivalent to passing the item BY CONTENT; the address of
identifier-3 cannot be modified by the called subprogram.
If the BY REFERENCE literal-2 phrase is
specified or implied then the object program processes literal-2 as described
for literal-3.
* If the BY CONTENT phrase is
specified or implied for a parameter, the called program cannot change the
value of this parameter as referenced in the CALL statement's USING phrase,
though the called program can change the value of the data item referenced by
the corresponding data-name in the called program's PROCEDURE DIVISION header.
The data description of each parameter in the BY CONTENT phrase of the CALL
statement must be the same, meaning no conversion or extension or truncation,
as the data description of the corresponding parameter in the USING phrase of
the PROCEDURE DIVISION header.
If the BY CONTENT phrase is specified or
implied for a parameter, the object program operates as if an additional data
item had been declared and this additional data item used as the parameter in a
BY REFERENCE phrase. If identifier-4 is specified, then both the implied data
description of the additional data item and its contents are identical to that
of identifier-4. If literal-3 is specified, then the implied data description
of the additional item is equivalent to an alphanumeric data item with the same
size as literal-3 and with its contents set to the value of literal-3. If
LENGTH OF identifier-5 is specified, then the data description of the
additional item is equivalent to PIC S9(n) USAGE COMP-5, where the value of n
is at least 9 and defines a data item that is large enough to hold the maximum
length of a data item in the COBOL system. The contents of the additional data
item are set to the number of bytes of storage allocated to identifier-5.
*If the BY VALUE phrase is specified or
implied for a parameter, the called program cannot change the value of this
parameter as referenced in the CALL statement's USING phrase, though the called
program can change the value of the data item referenced by the corresponding
data-name in the called program's PROCEDURE DIVISION header. The object program
operates, conceptually, as if an additional data item had been declared in a
system area (typically the stack), available to non-COBOL languages for passing
parameters and that this additional data item occupies the same storage area as
the data item in the called program.
If identifier-6 is specified and is BINARY, COMP-4, COMP-5 or COMP-X, then the data description of the additional data item is identical to that of identifier-6, except its usage is COMP-5. The contents of the additional data item are identical to the COMP-5 representation of the contents of identifier-6. This conversion and representation facilitates calling non-COBOL programs.
Otherwise, if identifier-6 is specified then the implied data description of the additional data item and its contents are identical to that of identifier-6.
If integer-1 is specified, then the data description of the additional item is equivalent to a signed numeric item USAGE COMP-5 that occupies the number of bytes of storage indicated by the value of integer-2, if specified, or the size of the system area otherwise (typically the size of a POINTER on the system).
If LENGTH OF identifier-7 is specified, then the data description of the additional item is equivalent to PIC S9(n) USAGE COMP-5, where the value of n is at least 9 and defines a data item that is large enough to hold the maximum length of a data item in the COBOL system. The contents of the additional data item are set to the number of bytes of storage allocated to identifier-7.
If the program being called is a COBOL program, each parameter in the BY VALUE phrase of the CALL statement must have a corresponding parameter declared in the USING phrase of the PROCEDURE DIVISION header that also has the BY VALUE phrase specified or implied.
The additional data item generated as a result of the CALL statement, described above, is related to this corresponding parameter in the called program, as follows.
If the additional data item was subject to conversion from BINARY, COMP-4, COMP-5 or COMP-X to COMP-5, then the data description of the corresponding parameter in the called program must be identical to that of the data description of the additional data item with the exception that the corresponding parameter's USAGE can be any of BINARY, COMP-4, COMP-5 or COMP-X. On entry to the called COBOL program, a conversion from the USAGE COMP-5 of the additional data item to the USAGE of the corresponding parameter in the called program is performed.
If the additional data item was not subject to conversion to COMP-5, the data description of each parameter in the called program must be the same as the corresponding additional data item. This means there is no conversion or extension or truncation, of the additional data item to match the corresponding parameter in the called program.
If the program being called is not COBOL, the size of the additional data item should not exceed the maximum size of the system area (typically the size of a POINTER on the system); otherwise the system might become catastrophically corrupt.
A called program can pass data to the
calling program either by using a parameter declared in the USING phrase of the
calling program or by means of a returned value. A called program returns a
value by means of an EXIT GIVING or GOBACK GIVING statement. As control is
returned from the called program to the calling program, the returned value is
held in a system area generally available for non-COBOL programs to return a
value.
The size of the system area (typically the size of a POINTER on the system) is determined outside the COBOL system and limits the maximum value the return value can take, but the return value might not utilize the full size of the system area. The returned value is available to the calling program after control is returned, either implicitly in the special register RETURN-CODE or explicitly in the data item specified in the GIVING phrase.
If the GIVING phrase is not specified and
the calling convention specifies updating the RETURN-CODE special register (see
the topic
The Special-Names
Paragraph) then the object program operates as if the
system area were declared as a COBOL numeric data item with USAGE COMP-5 and
the same size as the system area and as if a MOVE statement had been executed
with the system area as the sending item and the RETURN-CODE special register
as the receiving item. If the GIVING INTO phrase is specified in
the calling program, identifier-8 must describe the same number of character
positions as is required to hold the return value in the system area and must
be of the type and usage that is implied for the returned value by the manner
in which the value was returned from the called program. When control returns
to the calling program, identifier-8 contains the return value. If the GIVING ADDRESS OF phrase is
specified in the calling program, the called program must return a value with
explicit or implicit USAGE POINTER. The object program operates as if the
system area were declared as a COBOL data item with USAGE POINTER and as if a
SET statement had been executed with the system area as the first operand and
TO ADDRESS OF identifier-9 as the second operand. It is an error to specify the GIVING
phrase for a called program that does not return a value. unless
that calling program has the recursive attribute.
The END-CALL phrase delimits the scope
of the CALL statement. Any values with implicit or explicit
USAGE POINTER
or USAGE
PROCEDURE-POINTER
that were originally derived from the address of a data item
or procedure
that is contained within a called program become invalid and must not be used after a CANCEL statement that references that called program is executed.
The OMITTED phrase is used to pass unused
parameters to a subprogram without having to declare a dummy data item. The OMITTED parameter is a BY REFERENCE
parameter, equivalent to passing a null address to the calling subprogram. It
is identical to BY VALUE 0 SIZE 4 but is subject to the type checking of call
prototypes as a BY REFERENCE parameter. If BY REFERENCE does not immediately
precede OMITTED, subsequent parameters are passed by the convention previously
in force and the omitted parameter is treated as if the program had specified
BY VALUE 0 SIZE 4. Mnemonic-name identifies the calling
convention that this program uses when invoking the called program. If the
calling convention assumed by the called program is different to that implied
by mnemonic-name, then the COBOL system may become corrupt. The run unit remains unaware of whether a
called program is a COBOL program or a non-COBOL program or procedure until the
called program has been located, prior to being made available for execution.
The form of the program-name cannot be used, in general, to determine whether
the program is a COBOL program or not. It is an error for a COBOL program and a
non-COBOL program or for two non-COBOL programs to have the same program-name.
* The BY CONTENT, BY REFERENCE
and BY VALUE
phrases are transitive across the parameters which follow them until another BY CONTENT, BY REFERENCE
or BY VALUE
phrase is encountered.
If no BY CONTENT, BY REFERENCE
or BY VALUE
phrase is specified prior to the first parameter, the BY REFERENCE phrase is assumed.
Format
2If none of identifier-1, literal-1 or
procedure-pointer-1 is specified, program-prototype-name-1 determines the
externalized program-name of the program being called, according to the rules
specified in the topic
The Repository
Paragraph If the NESTED phrase is specified, the common or
contained program that has literal-1 specified in the Program-ID paragraph is
used to determine the characteristics of the called program. If the NESTED phrase is not specified,
program-prototype-name-1 is used to determine the characteristics of the called
program. If an argument is specified without any of the
keywords BY REFERENCE, BY CONTENT, or BY VALUE, the manner used for passing
this argument is determined as follows:
Control is transferred to the called program in a
manner consistent with the entry convention specified for the program. If an OMITTED phrase is specified or a trailing
argument is omitted, the omitted-argument condition for that parameter
evaluates to true in the called program. (See the topic
The Omitted-Argument
Condition in the chapter Procedure
Division.) If a parameter for which the omitted-argument
condition is true is referenced in a called program, except as an argument or
in the omitted-argument condition, you will get runtime error 203.
